Product Details

Gas Tracer Confined Space PPM LEL Detector w/ CSA Certification

The Gas Tracer is excellent for testing and detection of small gas leaks. Built around high-quality micro-sensor technology, the Gas Tracer is RKI’s smallest personal 5 sensor monitor with a built in sample pump.

Weighing only 12.3 ounces, it has many features which set the Gas Tracer apart from the competition. For example, it can monitor the standard gas safety hazards for gas/pipeline operations, (LEL combustibles, Oxygen content, and Carbon Monoxide), and it also has a high-sensitivity ppm CH4 leak tracker mode which reads down to 10 ppm. It can also measure 100% volume Methane and dynamically display either % LEL, or % volume with its auto-ranging ability. The Gas Tracer is excellent for gas line purge testing and detection of small gas leaks.

The Gas Tracer’s large LCD display shows all gas readings, battery level, current time, and will automatically backlight in alarm conditions. Other standard mode alarm types include vibration, visual, and audible alarms that can be set to latching or non-latching. Controlled by a microprocessor, the Gas Tracer continuously checks itself for sensor connections, low battery, circuit trouble, low flow, and calibration errors. The Gas Tracer can operate on either a Li-Ion battery pack or an alkaline battery pack. The batteries are simple to replace requiring no tools to access the removable battery compartment or pack. Calibration and bump test intervals and reminders are user adjustable and can be set to either go into alarm or to lock the user out of normal measurement mode once a calibration period has expired. Calibrations can be performed automatically or individually in single calibration mode. The Gas Tracer is also compatible with the economical SDM-2012 single channel calibration station.

Features:

CSA Certified Version
Monitors ppm, LEL, and % volume methane, O2 and CO
PPM leak detector, detects down to 10 ppm CH4
“Leak tracker” audible/visual alarm mode for CH4 and CO
0 to 100% volume Methane option
Bump test reminder option
Snap-logging - on demand data recording
Pump pause on demand extends battery life
Status indicators: — Pump active, microprocessor status and battery level
Internal sample drawing pump with up to 50 foot range
Lithium ion or alkaline battery packs (interchangeable)
Alarm latching or non-latching
Up to 600 hours of datalogging with alarm trends
TWA and STEL readings with lunch-break mod
Intrinsically safe, ATEX/IECEx/CE or c CSA us (Optional)
High dust and water resistance design
2 year warranty

Instrument Price Includes:
10’ hose probe, and Quick Reference Card. The battery and charger (if applicable) option selected is also included.

Gas Tracer Confined Space PPM LEL Detector w/ CSA Certification

Gas Detected	Combustible Gases (Methane as standard)	% Volume Methane	PPM Methane	Oxygen (O2)	Carbon Monoxide (CO)
Detection Principle	Catalytic combustion	Thermal conductivity	MOS/catalytic	Galvanic cell	Electrochemical cell
Detection Range	0 ~ 100% LEL	0 ~ 100% Vol.	0 ~ 5000 ppm optional 10,000 ppm range version available	0 ~ 40% Vol.	0 ~ 500 ppm
Accuracy Statement (whichever is greater)	± 5% of reading or ± 2% LEL	± 5% of reading or ± 2% of full scale	± 10% of reading or ± 50 ppm CH4	± 0.5% O2	± 5% of reading or ± 5 ppm CO
Sampling Method	Internal sample pump, flow rate nominal 0.5 LPM, includes hydrophobic filter
Display	Digital LCD with 7 segments, auto backlight during alarm
Preset Alarms (User Adjustable)	1st alarm 10% LEL 2nd alarm 50% LEL Over alarm 100% LEL	No alarms for % Vol. CH4	Increasing tone/ light pulse as concentration increases	Low alarm 19.5% High alarm 23.5% Over alarm 40.0%	1st 25 ppm 2nd 50 ppm TWA 25 ppm STEL 200 ppm Over 500 pp
Alarms Types	Leak Tracker Mode: Escalating audible/visual alarm, changes with gas level (audible can be turned off) Gas alarms: 1st and 2nd, STEL, TWA (user adjustable) and OVER Trouble alarms: Sensor connection, low battery, low flow, circuit trouble and calibration error
Alarm Methods	Gas alarms: Flashing lights, two tone buzzer, and vibration Trouble alarms: Flashing lights, trouble displayed, intermittent buzzer, and vibration
Operating Temp. and Humidity	-20°C to +50°C (-4°F to +122°F) 0 to 95% RH, non-condensing
Response Time	Within 30 seconds (T90)
Continuous Operation	Alkaline battery: 15 hours Li-Ion battery: 10 hours 70°F (21°C)
Power Source	Li-Ion battery pack, or 3 “AA” Alkaline battery pack; interchangeable
Safety Rating	ATEX, TIIS, IECEx, CE, or optionally: c CSA us classified, as intrinsically safe. Class I, Division 1, Groups A, B, C, D Note: Either ATEX (USA and worldwide) or CSA (Canada) version must be specified when ordering.
Dimension and Weight	Approx. 143 (H) x 71 (W) x 43 (D) mm (5.6” H x 2.8” W x 1.6” D), approx. 350 g (12.3 ounces)
Case Material	High dust and water resistant design. RFI shielded high impact plastic with protective rubber overmolding
Controls	Five buttons: POWER / ENTER, DISPLAY, AIR, RESET, SHIFT
Standard Accessories	• Belt clip • Rubber nozzle, 2.5” • Datalogging software • 10” Probe • Manual • Quick reference card • 10’ Hose • Training CD
Optional Accessories	• SDM-2012 calibration stations • Calibration kit • Li-Ion battery pack • AC or DC Charger • Sample draw hoses (10’ standard, up to 50’ max. available) • Carrying case
Configurations	1, 2, 3, 4, or 5 sensor units Li-Ion or alkaline battery pack options
Warranty	Two years material and workmanship
