| Display
|
Touch panel TFT liquid crystal (3.5 inch, 320×240 image element QVGA, RGB1677 million colors) Back light
|
| LED
|
3 color [Green, Red, Orange]. Each status is indicated by Lighting / Blinking
|
| BUMP test
|
Standard setting values
AIR Flush time: 15sec, GAS time: 20sec, AIR Purge time: 5sec
Threshold value: ±50%, Auto Calibration: OFF, Auto alarm function check: ON
Auto print: OFF
Setting range
AIR Flush time: 15~120sec
GAS time: 20~120sec
AIR Purge time: 5~120sec
Threshold value: ±10~50%
Auto calibration: ON, OFF
Auto alarm function check: ON, OFF
Auto print: ON, OFF
Bump test result: Displayed on TFT liquid crystal
|
| Calibration
|
Standard setting values
AIR Flush time: 30sec, GAS time: 90sec, AIR Purge time: 30sec
Auto alarm function check: ON, Auto print: OFF
Setting ranges
AIR Flush time: 15~120sec
GAS time: 20~120sec
AIR Purge time: 5~120sec
Auto alarm function check: ON, OFF
Auto print: ON, OFF
Calibration result: Displayed on touch screen display
|
| Power (AC adaptor)
|
100~240VAC~50/60Hz
|
| Dimension, weight
|
5.11”(W) x 13’(H) x 7.2”(D)in Approx. 3.7lb
|
| Operation temperature, humidity
|
0~104F, below 95~RH (no condensing)
|
| USB printer port
|
A type: Connects SDM-6000 printer (SII, DPU-S245) via USB cable
|
| RJ-45 connector
|
Ethernet port for a LAN connection
|
| SD card slot
|
Compatible with SD & SDHC cards
|
| Joint connector
|
Connecting SDM-6000 (Max 10 units) and SV-3
|
| Inlet
|
4 inlets: GAS 1 / GAS 2 / GAS 3 / AIR
|
| Certification
|
CE marking
|
| Standard Functions
|
Charging, Cal. cap fitting status monitoring, Power ON function, Alarm activation check, multi language (English, German, Japanese, Korean, Russian, Portuguese, Spanish, Italian, French), backlight adjusting, buzzer function, self-diagnosis for instruments connection
|
| Standard accessory
|
Operating manual, filter, connecting plate, wall mount plate, PC controller software
|
| Software
|
PC controller software included as standard. Windows 7 & 10 compatible
|
| Optional accessory
|
SV-3 solenoid valve adds 3 additional calibration gas inputs
AC adaptor (15W output), AC adaptor (100W output)
Calibration Station utility software
Calibration gas & regulators
Tubing
Battery powered printer
|
