Water Vapor Detection Tubes 0.1 (1 - 40 mg/l)
For short-term measurements more than 160 Draeger-Tubes are available to measure the spot concentrations of specific gases. Measurement usually takes between 4 seconds and 15 minutes. The tubes are used with the Draeger-Tube Accuro Pump.
A wide range of different gases and vapors can be detected and measured, such as:
- Determining and measuring concentration peaks
- Measuring personal exposure in the inhalation area
- Detecting leaks in pipelines, gas installations etc.
- Air analysis in sewers, shafts and confined spaces
Water Vapor Detection Tubes 0.1 (1 - 40 mg/l)
| Standard Measuring Range: |
1 to 40 mg/L |
| Number of Strokes (n): |
10 |
| Time for Measurement: |
approx. 2 min |
| Standard Deviation: |
±10 to 15 % |
| Color Change: |
yellow ? red brown |
| Temperature: |
0 to 40° C |
| Reaction Principle: |
H2O + SeO2 + H2SO4 → reddish brown reaction product |
| Cross Sensitivity: |
Low molecular weight alcohols are indicated. A variety of other organic compounds, such as petroleum hydrocarbons are indicated. |
Water Vapor Detection Tubes 0.1 (1 - 40 mg/l)
