Water Vapor Detection Tubes 0.1 (1 - 40 mg/l)
For short-term measurements more than 160 Draeger-Tubes are available to measure the spot concentrations of specific gases. Measurement usually takes between 4 seconds and 15 minutes. The tubes are used either manually with the Draeger-Tube Accuro Pump or automatically with the Draeger X-act 5000.
A wide range of different gases and vapors can be detected and measured, such as:
- Determining and measuring concentration peaks
- Measuring personal exposure in the inhalation area
- Detecting leaks in pipelines, gas installations etc.
- Air analysis in sewers, shafts and confined spaces
Water Vapor Detection Tubes 0.1 (1 - 40 mg/l)
|
Standard Measuring Range:
|
1 to 40 mg/L
|
|
Number of Strokes (n):
|
10
|
|
Time for Measurement:
|
approx. 2 min
|
|
Standard Deviation:
|
�10 to 15 %
|
|
Color Change:
|
yellow ? red brown
|
|
Temperature:
|
0 to 40� C
|
|
Reaction Principle:
|
H2O + SeO2 + H2SO4 ? reddish brown reaction product
|
|
Cross Sensitivity:
|
Low molecular weight alcohols are indicated. A variety of other organic compounds, such as petroleum hydrocarbons are indicated.
|
Water Vapor Detection Tubes 0.1 (1 - 40 mg/l)
