| Inspection Efficiency |
| MSX (Multi-Spectral Dynamic Imaging) |
IR image enhanced with visible camera detail |
| FLIR Ignite |
Instant upload to cloud storage over Wi-Fi |
| FLIR Thermal Studio Suite |
Compatible with full range of analysis and reporting software |
| Capacitive Touchscreen |
Access to onscreen menus, features, and keyboards |
| Text |
Text annotation on image using onscreen keyboard |
| Gallery |
Thumbnails and custom folder structure |
| Imaging and Optical |
| IR Resolution |
320 × 240 (76,800 pixels) |
| Thermal Sensitivity/NETD |
<0.05°C (0.09°F) / <50 mK |
| Focus |
Fixed focus |
| Image Frequency |
9 Hz |
| Color Palettes |
Iron, White hot, Black hot, Rainbow, Arctic, Lava, Rainbow HC |
| Digital Camera |
5 MP |
| Picture-in-Picture |
IR area on visual image |
| Detector Type |
Uncooled microbolometer |
| Field of View (FOV) |
33° |
| F-number |
1.4 |
| Image Modes |
Thermal MSX, Thermal, Picture-in-Picture, Thermal blending, Digital camera |
| Minimum Focus Distance |
0.36 m (1.18 ft) |
| Spatial Resolution (IFOV) |
1.8 mrad |
| Spectral Range |
7.5 µm to 13 µm |
| Measurement & Analysis |
| Accuracy |
±2°C (±3.6°F) or ±2% of reading, for ambient temperature 10°C to 35°C (50°F to 95°F) and object temperature above 0°C (32°F) |
| Object Temperature Range |
-20°C to 550°C (-4°F to 1022°F) in two ranges |
| Measurements Correction |
Emissivity; matt/semi-matt/semi-gloss + custom value, reflected apparent temperature, atmospheric compensation |
| Set-up Commands |
Local adaptation of units, language, date and time formats |
| Spot Meter |
Center spot; box with min/max |
| User Interface |
| Display |
3.5 in, 640 × 480 color LCD |
| Flashlight |
Bright LED |
| Power |
| Battery Operating Time |
4 hours |
| Battery Type |
Rechargeable Lithium-ion battery |
| Charging System |
Battery is charged inside the camera or in specific charger |
| Charging Time |
2 h |
| Power Management |
Automatic shutdown |
| User Interface |
| Display |
3.5 in, 640 × 480 color LCD |
| Flashlight |
Bright LED |
| Environmental & Certifications |
| Certifications |
UL, CSA, CE, PSE and CCC, WEEE 2012/19/EC, RoHs 2011/65/EC |
| EMC |
EN 301 489-1
EN 301 489-17
EN 61000-6-3
EN 61000-6-2
FCC 47 CFR Part 15 Class B |
| Humidity (Operating and Storage) |
IEC 60068-2-30/24 h 95% relative humidity |
| Operating Temperature Range |
-15°C to 40°C (5°F to 122°F) |
| Wi-Fi |
Standard: 802.11 a/b/g/n (2.4 GHz and 5 GHz) |
| Shock |
25 g (IEC 60068-2-27) |
| Storage Temperature Range |
-40°C to 70°C (-40°F to 158°F) |
| Vibration |
2 g (IEC 60068-2-6) |
| General |
| Camera Size (L × W × H) |
244 mm × 95 mm × 140 mm (9.6 in × 3.7 in × 5.5 in) |
| Camera Weight (including battery) |
0.590 kg (1.30 lb) |
| List of Contents |
Infrared camera, hard transport case, battery (inside camera) + extra battery, USB cable, power supply/ charger with EU, UK, US and Australian plugs, battery charger, FLIR Thermal Studio Starter, and printed documentatio |
| Packaging Size |
385 mm × 165 mm × 315 mm (15.2 in × 6.5 in × 12.4 in) |
| Storage Media |
Internal memory and onboard FLIR Ignite cloud connectivity (with Wi-Fi) |
