UCF 6000 Thermal Imaging Camera

There are no reviews yet. | Write a review
Item #: 8324882
MFG: Draeger
UOM: Each
Min Order: 0
Order Qty: Must order in multiples of 1
View additional buying options
Product Details

UCF 6000 Thermal Imaging Camera

Technologically advanced yet easy to use, the Draeger UCF 6000 thermal imaging camera delivers excellent image quality under the most extreme conditions. As a true one handed thermal imaging system, the Draeger UCF 6000 means to other hand is always free when the user needs it. The Draeger UCF 6000 is equipped with a rugged and durable housing that resists heat, water, smoke and dust. The Lithium-Ion battery technology powers the UCF 6000 for up to 4 hours.

The Draeger UCF 6000 provides excellent image quality in settings where fire, smoke, and darkness make visibility extremely limited and navigation difficult. A resolution of 160 x 120 pixels and a wide field of view (47°) provide the necessary image sharpness and dynamic range to stay safe and get the job done right. The UCF 6000 also features a new adapted brightness sensor, so firefighters no longer have to "shadow" the display when operating the camera in direct sunlight.

The integrated laser pointing feature allows users to point to hotspots and other areas of concern without changing their grip on other equipment. This enables the user to illustrate a recommended "plan of attack" to fellow firefighters.


  • Unbelievably detailed image for 160 x 20 thermal
  • Brightness sensor adapts display to all lighting conditions, no need to cup hands over screen
  • Integrated laser pointer pinpoints hazards and aids communications
  • Snapshot function allows freeze frame imaging of difficult areas
  • 160 x 120 pixels resolution provides superior image quality
  • One hand operation for ease of use and enhanced mobility
  • Lightweight and ergonomic design minimizes fatigue
  • Extended life battery offers confidence and peace of mind

UCF 6000 Thermal Imaging Camera

Dimensions of camera:
(B x H x T)
125 x 260 x 110 mm
Display Technology: Liquid crystal display (LCD)
Display Size (diagonal): 9 cm (3.5")
Protection class: IP 67
Infrared-specs: Type of Sensor: a-Si Microbolometer Array
Resolution: 160 x 120 pixel
IR spectral: 7 to 14 μm
Temp. sensitivity: typically 0.035° C
Picture frequency: 50 Hz
Optics: Focus: from 1 m to infinity
Field of view: Horizontal - 47° / Vertical - 32° /
Diagonal 62°
Operation time :
(at 23°C)
w/ battery - typically 4 hours
w/ alkaline power supply - typically 2 hours
Temperature measurement: Digital temperature display: -40°C ... 1,000°C
Battery technology: Rechargeable li-ion batteries
Battery display: Precise 4-level battery indicator

UCF 6000 Thermal Imaging Camera

Kit Includes:

  • UCF 6000
  • Desktop charger
  • Charging cords
  • IFU
  • Software disc
  • Crawling plate

UCF 6000 Thermal Imaging Camera
