Triethylamine Detection Tubes 5/a (5 - 60 ppm)
For short-term measurements more than 160 Draeger-Tubes are available to measure the spot concentrations of specific gases. Measurement usually takes between 4 seconds and 15 minutes. The tubes are used either manually with the Draeger-Tube Accuro Pump or automatically with the Draeger X-act 5000.
A wide range of different gases and vapors can be detected and measured, such as:
- Determining and measuring concentration peaks
- Measuring personal exposure in the inhalation area
- Detecting leaks in pipelines, gas installations etc.
- Air analysis in sewers, shafts and confined spaces
Triethylamine Detection Tubes 5/a (5 - 60 ppm)
| Standard Measuring Range: |
5 to 60 ppm |
| Number of Strokes (n): |
5 |
| Time for Measurement: |
approx. 3 min |
| Standard Deviation: |
±10 to 15 % |
| Color Change: |
yellow -> blue |
| Temperature: |
10 to 40° C |
| Absolute Humidity: |
5 to 12 mg H2O / L |
| Reaction Principle: |
(C2H5)3N + Acid ??> blue reaction product |
| Cross Sensitivity: |
Other basic substances such as organic amines and ammonia are indicated, but with different sensitivities. |
Triethylamine Detection Tubes 5/a (5 - 60 ppm)
