Acetic Acid Detection Tube (1 to 100 ppm)

There are no reviews yet. | Write a review
Item #: 81
MFG: GasTec
UOM: Box of 10
Min Order: 0
Order Qty: Must order in multiples of 1
$86.87 Was: $97.33
View additional buying options

Acetic Acid Detection Tube (1 to 100 ppm)

Measures Acetic Acid with a range of 1 to 100 ppm.

  • Measuring Range (Acetic Acid):
    • 1 to 2 ppm
    • 2 to 50 ppm
    • 50 to 100 ppm
  • Number of Pump Strokes: 2, 1, 1/2
  • Correction Factor: 1/2, 1, 2
  • Sampling Time: 45 seconds per pump stroke
  • Detecting Limit: 0.2 ppm (2 pump strokes)
  • Changes from Pink to Yellow
  • Reaction Principle: CH3CO2H + Base → Reaction product
  • Relative Standard Deviation: 10% (for 2 to 10 ppm), 5% (for 10 to 50 ppm)
  • Shelf Life: 3 Years
  • Store the tubes at cool and dark place

Other substances measurable with this detection tube:

Substance: Correction Factor: No. of Pump Strokes: Measuring Range:
Acetic anhydride Factor: 0.3 1 0.6 to 15 ppm
Acrylic acid Factor: 1.0 1 2 to 50 ppm
Formic acid Factor: 2.6 1 5.2 to 130 ppm
Isovalenic acid Factor: 1.0 1 2 to 50 ppm
Maleic anhydride Factor: 0.4 1 0.8 to 20 ppm
Methacrylic acid Factor: 0.9 1 1.8 to 45 ppm
Propionic acid Factor: 1.5 1 3 to 75 ppm
