Acetic Acid Detection Tube (1 to 100 ppm)
Measures Acetic Acid with a range of 1 to 100 ppm.
- Measuring Range (Acetic Acid):
- 1 to 2 ppm
- 2 to 50 ppm
- 50 to 100 ppm
- Number of Pump Strokes: 2, 1, 1/2
- Correction Factor: 1/2, 1, 2
- Sampling Time: 45 seconds per pump stroke
- Detecting Limit: 0.2 ppm (2 pump strokes)
- Changes from Pink to Yellow
- Reaction Principle: CH3CO2H + Base ? Reaction product
- Relative Standard Deviation: 10% (for 2 to 10 ppm), 5% (for 10 to 50 ppm)
- Shelf Life: 3 Years
- Store the tubes at cool and dark place
Other substances measurable with this detection tube:
| Substance:
|
Correction Factor:
|
No. of Pump Strokes:
|
Measuring Range:
|
| Acetic anhydride
|
Factor: 0.3
|
1
|
0.6 to 15 ppm
|
| Acrylic acid
|
Factor: 1.0
|
1
|
2 to 50 ppm
|
| Formic acid
|
Factor: 2.6
|
1
|
5.2 to 130 ppm
|
| Isovalenic acid
|
Factor: 1.0
|
1
|
2 to 50 ppm
|
| Maleic anhydride
|
Factor: 0.4
|
1
|
0.8 to 20 ppm
|
| Methacrylic acid
|
Factor: 0.9
|
1
|
1.8 to 45 ppm
|
| Propionic acid
|
Factor: 1.5
|
1
|
3 to 75 ppm
|
Acetic Acid Detection Tube (1 to 100 ppm)
