Carbon Disulfide Detection Tubes 30/a (32 - 3200 ppm)

There are no reviews yet. | Write a review
Item #: CH23201
MFG: Draeger
UOM: Box of 10
Min Order: 0
Order Qty: Must order in multiples of 1
$105.00
View additional buying options
Product Details

Carbon Disulfide Detection Tubes 30/a (32 - 3200 ppm)

For short-term measurements more than 160 Draeger-Tubes are available to measure the spot concentrations of specific gases. Measurement usually takes between 4 seconds and 15 minutes. The tubes are used either manually with the Draeger-Tube Accuro Pump or automatically with the Draeger X-act 5000.

A wide range of different gases and vapours can be detected and measured, such as:

  • Determining and measuring concentration peaks
  • Measuring personal exposure in the inhalation area
  • Detecting leaks in pipelines, gas installations etc.
  • Air analysis in sewers, shafts and confined spaces

Carbon Disulfide Detection Tubes 30/a (32 - 3200 ppm)

Standard Measuring Range: 0.1 to 10 mg/L
Number of Strokes (n): 6
Time for Measurement: approx. 1 min.
Standard Deviation: ±15 to 20 %
Color Change: pale blue ?> brown
Temperature: 0 to 40° C
Absolute Humidity: < 30 mg H2O / L
Reaction Principle: 2 CS2 + 4 NHR2 + Cu2+ ?>
Cu(SCSNR2)2 + 2 NH2R2+
Cross Sensitivity: Hydrogen sulfide is indicated, producing a pale green discoloration. It is impossible to measure carbon disulfide in the presence of hydrogen sulfide.
